Argon Purge Plugs

Argon Purge Plugs

Ladle Purging System is a critical functional refractory solution designed for modern secondary refining processes (such as LF, VOD, and AOD). This integrated set, consisting of a high-precision Purging Plug and a heavy-duty Well Block (Seating Block), is engineered to inject inert gases (Argon or Nitrogen) into the molten steel. This process is essential for homogenizing temperature, balancing chemical composition, and removing non-metallic inclusions to produce high-purity steel. Product Features 1.Superior Stability: Optimized Corundum-Spinel/Chrome-Corundum formula for excellent erosion and corrosion resistance. 2.AExtreme Thermal Resistance: High thermal shock stability (1100°C to water) prevents spalling and cracking during rapid cooling/heating. 3.Precise Flow Control: Engineered slot and pore structures guarantee stable gas permeability and high stirring efficiency. 4.Safety & Fit: Precision-molded Well Blocks ensure a perfect seal with the plug, preventing steel leakage and ensuring a long service life.
Send Inquiry
Description
Technical Parameters

product-1000-554



product-1000-787



Argon purge plugs are also called porous plugs



During smelting process, molten steel needs to be fulled blended, so C content and free Oxygen inside could react fully with smelting slags and result to clean steel. Argon through purging plugs is blown into the molten steel to help blending.



Materials for argon purge plugs are generally corundum chromite, with stainless steel shell outside. There are several types of purging plugs, including porous plugs with porous body inside, porous plugs with segments, porous plugs with slots etc. Up to now, slot plugs are most widely used. It's shaped under high pressure hydraulic press machine.



Inside the argon purge plugs, residual thickness indicator is applied to warn service life of the plugs.



Function refractories for continuous casting steel is a kind of advanced refractories aimed for clean steel. With function refractories, molten steel flow is better controlled, and could be protected from Oxygen during casting.



Function refractories for steel continuous casting generally include refractories from steel Ladle to Tundish and Tundish to Copper Mould Tube.



Function refractories are generally combined nozzles without binding agent, so the dimension and surface of such refractories are strictly controlled to match each other tightly.

product-1000-1086



product-1000-862



product-1000-914



product-1000-909

FAQ

Q1: Are you manufacturing?

A1:LONG KETER is a manufacturer with more than 16 years of experience in refractory industry, welcome to visit us.


Q2: Are there free samples?
A2: Yes, free samples are provided. The partners should bear the shipping cost. Please tell us which product you are interested in for more details.



Q3: Can I customize it?
A3: Yes, LONG KETER factory supports customized refractory bricks in size, shape, chemical composition, etc. There are more than 20 engineers OEM/ODM ready to customize solutions for you.



Q4: I have a project, I want the whole solution, can you prove it?
A4: No problem, we have a professional technical team and have very rich experience in the refractory industry, just need you to send us some requirements of your project, we can provide one-stop service from solution.
